Host Interface
USB 2.0 (Compatible with USB 1.1) Universal Serial Bus 2.0/1.1 (USB2.0/1.1), UHCI (Universal Host Controller Interface), OHCI (Open Host Controller Interface)
Integrated USB Transceiver
Dynamic feedback control, stable slew rate, independent external loading
Power Supply
None - Provided By USB Port (Low 3.3V)
Power Consumption
Operating Current	70 mA maximum
Supported Operating Systems
Windows ME, Windows 2000, Windows XP, Windows Vista™ and Mac OS 9.0 and Higher, Windows 98SE (Driver Required)
Environment
Operating Temperature	0 to +70 °C
Storage Temperature	-20 to +80 °C
Relative Mumidity Operation	Commercial Value
Relative Humidity Storage	Commercial Value
LED
Transmitting / Receiving Data	LED in Flashing Mode
Device is Connected and Inactive	LED is On
System Performance
Data Retention	10 Years (normal operation)
Read/Write Operation	1,000,000 Times (normal operation)
Reading Speed	up to 16MB/sec.*
Writing Speed	up to 10MB/sec.*
Miscellaneous
SKATE DRIVE Dimensions	23mm (Width) x 4.8mm (Height) x 95mm (Length)
SURF DRIVE Dimensions	23mm (Width) x 4.8mm (Height) x 95mm (Length)
SNOW DRIVE Dimensions	24mm (Width) x 4.9mm (Height) x 95mm (Length)
Weight	0.3 oz
Software Installation	None - USB Plug and Play Technology
Uninstall Procedures	None - Simply Unplug USB Flash Drive
Self-bootable	No
Storage Media	NAND or AG-AND Type Flash Memory

*Speed may very depending on USB Flash Drive capacity. 1GB USB Flash Drive is used for benchmark.

Please note: For All Flash Media Devices, 1 megabyte = 1 million bytes; 1 gigabyte = 1 billion bytes. Actual useable capacity may vary. Some of the listed capacity is used for formatting and other functions, and thus is not available for data storage.
